Texas Instruments ADS58H40IZCR
Production
In StockPrice and Stock
Authorized Distributors
Non-Authorized Stocking Distributors
Non-Authorized Dealers
| Distributor | SKU | MOQ | Pkg | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ADS58H40IZCR | 1,643 | 1 | Tray | 1d | ||||||||
| ADS58H40IZCR | 4,340 | 1d | ||||||||||
| ADS58H40IZCR | 1,421 | 100 | Bulk | 3d | ||||||||
| 43728-ADS58H40IZCR | 1,700 | 1 | 3d | |||||||||
| ADS58H40IZCR | 17,295 | >1wk |
Technical Specifications
Physical
Case/PackageBGA
Contact PlatingCopper, Silver, Tin
MountSurface Mount
Number of Pins144
Technical
Integral Nonlinearity (INL)5.25 LSB
InterfaceDDR, LVDS
Max Operating Temperature85 °C
Max Power Dissipation1.8 W
Max Supply Voltage3.45 V
Min Operating Temperature-40 °C
Min Supply Voltage1.8 V
Number of A/D Converters4
Number of Analog Inputs4
Number of Bits14
Number of Channels4
Number of Converters4
Number of Inputs4
Power Consumption1.46 W
Power Dissipation1.55 W
Resolution1.75 B
Sampling Rate250 Msps
Signal to Noise Ratio (SNR)71 dB
Supply TypeAnalog, Digital
Dimensions
Height1.5 mm
Length10 mm
Thickness950 µm
Width10 mm
Inventory History
3 month trend: +0.00%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
1 part available
Documents
Download datasheets and manufacturer documentation for Texas Instruments ADS58H40IZCR.
Texas Instruments
Upverter
SHENGYU ELECTRONICS
Alternate Parts
This Part
Alternate Parts
Price @ 1000
$ 230.45
$ 229.886
Stock
162,174
22,703
Authorized Distributors
2
0
Case/Package
BGA
BGA
Number of Pins
144
144
Number of Bits
14
14
Sampling Rate
250 Msps
250 Msps
Polarity
-
-
Interface
DDR, LVDS
DDR, LVDS
Integral Nonlinearity (INL)
5.25 LSB
5.25 LSB
Differential Nonlinearity
-
-
Number of A/D Converters
4
4
Min Supply Voltage
1.8 V
1.8 V
Max Supply Voltage
3.45 V
3.45 V
Supply Chain
Lifecycle StatusProduction (Last Updated: 6 days ago)
Manufacturer Lifecycle StatusACTIVE (Last Updated: 6 days ago)
Engineering Resources
View Evaluation kits and Reference designs for Texas Instruments ADS58H40IZCR.
Evaluation Kit
Related Parts
Analog DevicesAD6657BBCZ
IF Receiver, Quad Channel, 11-bit, 200Msps, SPI Interface, 144-Pin CSP-BGA Tray
Analog DevicesAD9249BBCZRL7-65
