Cornell Dubilier SEK100M050ST
$ 0.23
Production
Inventory History
3 month trend: -0.56%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
1 part available
Datasheets & Documents
Download datasheets and manufacturer documentation for Cornell Dubilier SEK100M050ST.
CAD Models
Download Cornell Dubilier SEK100M050ST symbol, footprint, and 3D STEP models from our trusted partners.
| SOURCE | eCAD | mCAD | FILES |
|---|---|---|---|
 Component Search Engine | SymbolFootprint | 3D | Download |
The partner site will open in a new tab when downloading their CAD models
By downloading CAD models from Octopart, you agree to our Terms & Conditions and Privacy Policy.
Alternate Parts
This Part
Alternate Parts
Price @ 1000
$ 0.23
$ 0.056
$ 0.056
Stock
40,592
533,542
533,542
Authorized Distributors
6
6
6
Capacitance
10 µF
10 µF
10 µF
Mount
Through Hole
PCB, Through Hole
PCB, Through Hole
Case/Package
Radial
Radial
Radial
Voltage Rating (DC)
50 V
50 V
50 V
Tolerance
20 %
20 %
20 %
ESR (Equivalent Series Resistance)
15.92 Ω
-
-
Life (Hours)
2000 hours
1000 hours
1000 hours
Ripple Current
50 mA
39 mA
39 mA
Height - Seated (Max)
10.9982 mm
11.9888 mm
11.9888 mm
Related Parts
Cornell DubilierSH100M050ST
Cap Aluminum Lytic 10uF 50V 20% (5 X 11mm) Radial 2mm 15.92 Ohm 50mA 2000h 105C
Cornell DubilierSEK100M063ST
Cap Aluminum Lytic 10uF 63V 20% (5 X 11mm) Radial 2mm 13.27 Ohm 55mA 2000h 105C
Descriptions
Descriptions of Cornell Dubilier SEK100M050ST provided by its distributors.
Capacitor Aluminum Electrolytic 10uF 50 Volt 20% (5 X 11mm) Radial 2 mm 15.92 Ohm 50mA 2000h 105C
CAPACITOR, ALUMINUM ELECTROLYTIC,10 UF,20%,50 VDC, RADIAL,5X11MM, ESR 15.92 OHMS
Aluminum Electrolytic Capacitor 10 microfarad
Aluminum Electrolytic Capacitors - Radial Leaded RADIAL 50V 10uF 105C
Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 50V, 20% +Tol, 20% -Tol, 10uF, Through Hole Mount
ALUMINUM ELECTROLYTIC CAPACITOR 10UF, 50V, 20%, RADIAL; Capacitance: 10µF; Voltage Rating: 50V; Product Range: SEK Series; Capacitance Tolerance: ± 20%; Capacitor Terminals: Radial Leaded; Diameter: 5mm; Lead
Aluminum Electrolytic Capacitor 10Uf, 50V, 20%, Radial; Rango De Producto:Serie Sek; Capacidad:10Μf; Tolerancia, Capacitancia:± 20%; Tensión Nominal:50V; Diámetro:5Mm; Terminales Del Condensador:Conexión Radial; Altura:11Mm |Cornell Dubilier SEK100M050ST
Manufacturer Aliases
Cornell Dubilier has several brands around the world that distributors may use as alternate names. Cornell Dubilier may also be known as the following names:
- CORNELL
- CDE
- Cornell Dubilier Electronics
- Cornell Dubilier Electronics (CDE)
- CORNELL DUBLIER
- DUBILIER
- CDC
- COR
- CORNELL DUB
- CORNELL DUBILIER ELECTRONICS INC
- CORNEL
- CORNELL DUBILIE
- CAP
- Cornell Dubilier - CDE
- DUB
- Cornell Dubilier / Illinois Capacitor
- CORNELL DUBI
- ELMENCO
- CORN DUB
- Cornell Dubilier Electron
- Cornell Dubilier Knowles
- CORNELL DUBILIER MARKETING
- CORNELL DUBLIER ELECTRONICS
- DUBIL
- CORNELL DUBILIER ELE
- CDE
- Illinois Capacitor
Inventory History
3 month trend: -0.56%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
1 part available
Technical Specifications
Physical
Case/PackageRadial
Dielectric MaterialAluminium
MountThrough Hole
Number of Terminals2
Technical
Capacitance10 µF
Dissipation Factor12 %
ESR (Equivalent Series Resistance)15.92 Ω
Leakage Current5 µA
Life (Hours)2000 hours
Max Operating Temperature105 °C
Min Operating Temperature-55 °C
Ripple Current50 mA
Schedule B8532220020
TerminationRadial
Tolerance20 %
Voltage Rating50 V
Voltage Rating (DC)50 V
Dimensions
Diameter5 mm
Height11 mm
Height - Seated (Max)10.9982 mm
Lead Diameter500 µm
Lead Length15 mm
Lead Pitch2 mm
Length11 mm
Terminal Pitch2 mm
Datasheets & Documents
Download datasheets and manufacturer documentation for Cornell Dubilier SEK100M050ST.
Compliance
Environmental Classification
Radiation HardeningNo
REACH SVHCYes
RoHSCompliant
