Analog Devices ADP3300ARTZ-5REEL7
$ 1.342
Production
Inventory History
3 month trend: +34.00%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
1 part available
Datasheets & Documents
Download datasheets and manufacturer documentation for Analog Devices ADP3300ARTZ-5REEL7.
CAD Models
Download Analog Devices ADP3300ARTZ-5REEL7 symbol, footprint, and 3D STEP models from our trusted partners.
| SOURCE | eCAD | mCAD | FILES |
|---|---|---|---|
 Component Search Engine | SymbolFootprint | 3D | Download |
 EE Concierge | SymbolFootprint | ||
 SnapEDA | Footprint | Download | |
 Ultra Librarian | SymbolFootprint | Download |
The partner site will open in a new tab when downloading their CAD models
By downloading CAD models from Octopart, you agree to our Terms & Conditions and Privacy Policy.
Alternate Parts
This Part
Alternate Parts
Price @ 1000
$ 1.342
$ 0.987
Stock
238,508
254,615
Authorized Distributors
6
1
Case/Package
SOT-23-6
-
Number of Pins
6
6
Number of Outputs
1
1
Max Output Current
50 mA
50 mA
Min Input Voltage
3 V
3 V
Max Input Voltage
12 V
12 V
Min Output Voltage
2.7 V
-
Max Output Voltage
5 V
-
Accuracy
0.8 %
0.8 %
Dropout Voltage
80 mV
-
Power Supply Rejection Ratio (PSRR)
60 dB
-
Supply Chain
Lifecycle StatusProduction (Last Updated: 3 years ago)
Manufacturer Lifecycle StatusPRODUCTION (Last Updated: 3 years ago)
Related Parts
Analog DevicesADP3330ARTZ3.3-RL7
IC REG LINEAR 3.3V 200MA SOT23-6 Linear Voltage Regulator IC Positive Fixed 1 Output 200mA SOT-23-6
Analog DevicesADP3330ARTZ-5-RL7
IC REG LINEAR 5V 200MA SOT23-6 Linear Voltage Regulator IC Positive Fixed 1 Output 200mA SOT-23-6
Analog DevicesADP3330ARTZ-2.5-R7
IC REG LINEAR 2.5V 200MA SOT23-6 Linear Voltage Regulator IC Positive Fixed 1 Output 200mA SOT-23-6
Descriptions
Descriptions of Analog Devices ADP3300ARTZ-5REEL7 provided by its distributors.
IC REG LINEAR 5V 50MA SOT23-6 Linear Voltage Regulator IC Positive Fixed 1 Output 50mA SOT-23-6
LDO Regulator Pos 5V 0.05A 6-Pin SOT-23 T/R
High Accuracy anyCAP® 50 mA Low Dropout Linear Regulator
ADP3300 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 80mV 1.15mm 50mA -55C~125C
Ldo, Fixed, 5V, 0.05A, Sot-23-6, 85Deg C; Output Type:Fixed; Input Voltage Min:3V; Input Voltage Max:12V; No. Of Outputs:-; Output Voltage - Nom:5V; Output Voltage Min:-; Output Voltage Max:-; Polarity:-; Max Output Current:50Ma Rohs Compliant: Yes |Analog Devices ADP3300ARTZ-5REEL7
Manufacturer Aliases
Analog Devices has several brands around the world that distributors may use as alternate names. Analog Devices may also be known as the following names:
- Analog Devices Inc
- ANALOG
- ANALOG DEVICE
- ADI
- ANALOG DEV
- AD
- ANA
- PMI
- Analog Devices Inc/Maxim Integrated
- ADV
- ADA
- ANALOG DEVIC
- PMI/AD
- ANALOG DEVI
- AD/PMI
- STOCK
- Analog Devices / Linear Technology
- ANALOG INTERGRATIONS CORP
- AD - Analog Devices
- PRECISION MONOLITIC INC
- ADI (Analog Devices Inc)
- ANADEV
- Analog Devices / Hittite
- ANALOG DEVICES (ADI)
- ANLOGDEVIC
- Analog Devices Inc.
- Maxim Analog Devices
- Analog Devices / Maxim Integrated
Inventory History
3 month trend: +34.00%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
1 part available
Technical Specifications
Physical
Case/PackageSOT-23-6
Number of Pins6
Technical
Accuracy0.8 %
Dropout Voltage80 mV
Max Input Voltage12 V
Max Operating Temperature85 °C
Max Output Current50 mA
Max Output Voltage5 V
Max Supply Current300 µA
Min Input Voltage3 V
Min Operating Temperature-40 °C
Min Output Voltage2.7 V
Nominal Supply Current300 µA
Number of Outputs1
Number of Regulators1
Operating Supply Current300 µA
Output Current50 mA
Output TypeFixed
Output Voltage5 V
Output Voltage Accuracy0.8 %
PolarityPositive
Power Supply Rejection Ratio (PSRR)60 dB
Quiescent Current1 µA
Schedule B8542390000
Dimensions
Height1.15 mm
Length2.9 mm
Width1.6 mm
Datasheets & Documents
Download datasheets and manufacturer documentation for Analog Devices ADP3300ARTZ-5REEL7.
Compliance
Environmental Classification
Lead FreeContains Lead
Radiation HardeningNo
REACH SVHCNo
RoHSCompliant
Compliance Statements
