C&K Components TFECF5SP0040C
$ 3.95
Production
Price and Stock
Authorized Distributors
Non-Authorized Stocking Distributors
Non-Authorized Dealers
| Distributor | SKU | Min | Pkg | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | TFECF5SP0040C | 0 | 250 | Bulk | ||||||||
| Newark | 35AH7473 | 0 | 1K | |||||||||
| Sager Electronics | TFECF5SP0040C | 0 | 1K | |||||||||
| TTI Europe | TFECF5SP0040C | 0 | 1 | Bulk | 18h | |||||||
| Component Stockers USA | TFECF5SP0040C | 1,298 | >1wk |
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Related Parts
C&K ComponentsTMCGF5SP0040C
Switch Snap Action N.O./N.C. SPDT Pin Plunger Quick Connect 1A 125VAC 30VDC 0.74N Screw Mount
C&K ComponentsTFCJF5ST1040C
Switch Snap Action N.O./N.C. SPDT Lever 1A 125VAC 30VDC 1.77N Screw Mount Quick Connect Bulk
C&K ComponentsTMCJF5SP0040C
Switch Snap Action N.O./N.C. SPDT Pin Plunger Quick Connect 1A 125VAC 30VDC 1.47N Screw Mount
Descriptions
Descriptions of C&K Components TFECF5SP0040C provided by its distributors.
Switch Snap Action N.O./N.C. SPDT Pin Plunger Quick Connect 1A 125VAC 30VDC 2.21N Screw Mount
Snap Acting/Limit Switch, SPDT, Momentary, 1A, 30VDC, 2.46mm, Quick Connect Terminal, Pin Plunger Actuator, Panel Mount
Switch Snap Action N.O./N.C. SPDT Pin Plunger Quic
SWITCH SNAP ACTION SPDT 1A 125V
Basic / Snap Action Switches Miniature Snap-acting Switch
Manufacturer Aliases
C&K Components has several brands around the world that distributors may use as alternate names. C&K Components may also be known as the following names:
- C&K
- CKCOMP
- C&K COMPONENTS INC
- C&K SWITCHES
- C&K SWITCH
- C&K Components Corp
- C AND K COMPONENTS
- C & K COMPONENT
- C&K COMPONEN
- C AND K
- C&K CONNECT
- C&K/ITT CANNON
- C & K COMPONENTS LLC
- C&K COMPO
- ITTE
- C & K COMPON
- Littelfuse - C&K
- C&K Aerospace
- C&K COMPONENTS (VA)
- ITT/C&K
- C&K / ITT INDUSTRIES
- C&K Switc
- C&K Components (Schadow)
- RAFI-USA INC / C&K COMPONENTS
- C & K Components Incorporated
- C&K Components
- C&K Components Ltd.
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
Actuator MaterialThermoplastic
Contact MaterialGold
Contact PlatingSilver
Housing MaterialThermoplastic
MountChassis Mount, Screw
Terminal MaterialBrass
Technical
Contact Current Rating1 A
Contact Voltage Rating (AC)125 V
Current Rating1 A
Differential Travel254 µm
Electrical Life300 kcycles
Insulation Resistance1 GΩ
Max Current Rating1 A
Max Operating Temperature85 °C
Max Voltage Rating (AC)125 V
Max Voltage Rating (DC)30 V
Min Operating Temperature-40 °C
Operating Force2.21 N
Operating Position14.7066 mm
OrientationStraight
Overtravel1.27 mm
Pretravel1.19 mm
Switch FunctionOn-Mom
TerminationQuick Connect
Throw ConfigurationSPDT
Voltage Rating (AC)125 V
Voltage Rating (DC)30 V
Dimensions
Depth10.2 mm
Height15.7 mm
Length29 mm
