Vishay SA28A-E3/54
$ 0.105
Production
Price and Stock
Authorized Distributors
Non-Authorized Stocking Distributors
Non-Authorized Dealers
| Distributor | SKU | Min | Pkg | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Avnet | SA28A-E3/54 | 12,000 | 4K | 23h | ||||||||
| Newark | 38AH2208 | 12,000 | 4K | Tape & Reel | ||||||||
| Future Electronics | 2997781 | 4,000 | 4K | Tape & Reel | ||||||||
| Verical | SA28A-E3/54 | 1,148 | 55 | |||||||||
| Arrow Electronics | SA28A-E3/54 | 1,148 | 1 |
Inventory History
3 month trend: -6.59%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Related Parts
Descriptions
Descriptions of Vishay SA28A-E3/54 provided by its distributors.
SA28A Series 500 W 28 V Uni-Directional Axial TVS Diode - DO-204AC (DO-15)
Trans Voltage Suppressor Diode, 500W, 28V V(RWM), Unidirectional, 1 Element, Silicon, DO-204AC
SA28A-E3/54, UNI-DIRECTIONAL TVS DIODE, 500W, 2-PIN DO-204AC
TVS Diode Single Uni-Dir 28V 500W 2-Pin DO-15 T/R
TVS DIODE 28VWM 45.4VC DO204AC
TVS, 28V, 500W, Uni-Directional
TVS DIODE, 500W, 28V, DO-204AC; TVS Pola; TVS DIODE, 500W, 28V, DO-204AC; Reverse Stand-Off Voltage Vrwm:28V; Breakdown Voltage Range:31.1V to 34.4V; Clamping Voltage Vc Max:45.4V; Peak Pulse Current Ippm:11A; Diode Case Style:DO-204AC; No. of Pins:2; Power Dissipation Pd:3W
Diode; Reverse Stand-Off Voltage, VRWM:28V; Termination Type:Axial Leaded; Operating Temperature Range:-55°C to +175°C; Package/Case:DO-204AC; Breakdown Voltage, Vbr:31.1V; Diode Type:Unidirectional TVS; Peak Pulse Power Ppk:500W ;RoHS Compliant: Yes
Manufacturer Aliases
Vishay has several brands around the world that distributors may use as alternate names. Vishay may also be known as the following names:
- VIS
- VISH
- VISHAY INTERTECHNOLOGY INC
- Vishay Thin Film
- VISHA
- Vishay Intertechnology
- Vishay Semiconductors
- VISAHY
- Vishay Intertech
- VISHY
- VISHAY INTERTECHNOLOGY ASIA PTE LTD
- Vishay Intertechnologies
- Vishay General Semiconductor - Diodes Division
- Vishay Semiconductor Opto Division
- VSHAY
- VISH/IR
- VSHY
- VSH
- VISHAY INTERTECHNOLOGY ASIA PT
- VISHAY ELECTRONIC
- VISHAY AMERICAS INC
- Vishay Semiconductor Diodes Division
- VISHAY OPTO
- VISHAY FOIL RESISTORS
- Vishay Polytech
- Vishay Semiconductor
- Vishay Sfernice
- Vishay Siliconix
- Vishay Dale
- Vishay BCcomponents
- Vishay Angstrohm
- Vishay Draloric
Inventory History
3 month trend: -6.59%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
Case/PackageDO-15
MountThrough Hole
Number of Pins2
Number of Terminals2
Technical
Breakdown Voltage32.75 V
Clamping Voltage45.4 V
DirectionUnidirectional
Element ConfigurationSingle
Leakage Current1 µA
Max Breakdown Voltage34.4 V
Max Operating Temperature175 °C
Max Power Dissipation3 W
Max Reverse Leakage Current1 µA
Max Surge Current11 A
Min Breakdown Voltage31.1 V
Min Operating Temperature-55 °C
Number of Channels1
Number of Elements1
Operating Supply Voltage28 V
PackagingCut Tape
Peak Pulse Current11 A
Peak Pulse Power 500 W
PolarityUnidirectional
Power Dissipation500 W
Reverse Breakdown Voltage31.1 V
Reverse Standoff Voltage28 V
Schedule B8541100080
TerminationAxial
Test Current1 mA
Working Voltage3.5 V
Dimensions
Diameter3.6 mm
Length7.5946 mm
Compliance
Environmental Classification
China RoHSNon-Compliant
Lead FreeLead Free
REACH SVHCYes
RoHSCompliant
