TE Connectivity / P&B KHU-17D12-24
$ 75.31
Obsolete
Inventory History
3 month trend: Restocked
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Datasheets & Documents
Download datasheets and manufacturer documentation for TE Connectivity / P&B KHU-17D12-24.
Supply Chain
Export Control Classification Number (ECCN) CodeEAR99
Introduction Date2008-03-19
Lifecycle StatusObsolete (Last Updated: 3 months ago)
LTB Date2024-11-29
LTD Date2025-12-19
Related Parts
TE Connectivity / P&BR10-E2X4-V700
Electromechanical Relay 24VDC 700Ohm 5A 4PDT (( 29.59mm 18.67mm 30.15mm)) THT General Purpose Relay
OmronMY4IN DC24 (S)
Relay,E-Mech,4PDT,Ctrl-V 24VDC,5A,250VAC/125VDC,Socket Mount,Blade Term,MYSeries
OmronMY4ZN-D2 DC24 (S)
Relay; SSR; Zero-Switching; Cur-Rtg 20A; Ctrl-V 12-24DC; Vol-Rtg 200-480AC; Pnl-Mnt
Descriptions
Descriptions of TE Connectivity / P&B KHU-17D12-24 provided by its distributors.
Power Relay 24VDC 5A 4PDT(28.2x21.8x38.1)mm Socket
Electromechanical Relay 4PDT 5A 24VDC 650Ohm Through Hole
Power/Signal Relay, 4 Form C, 4PDT, Momentary, 0.038A (Coil), 24VDC (Coil), 850mW (Coil), 5A (Contact), DC Input, Random, AC/DC Output, Panel Mount
RELAY, 4PDT, 120VAC, 28VDC, 5A; Contact Configuration:4PDT; Coil Voltage:24VDC; Contact Current:5A; Product Range:KHU Series; Relay Mounting:Through Hole; Coil Type:Non Latching; Contact Voltage VAC:120VAC; Relay Terminals:Solder RoHS Compliant: Yes
KHU-17D12-24=KH Relay Type: Industrial Panel Plug-In Coil Magnetic System: Monostable, DC Coil Power Rating DC: 850 mW Coil Resistance: 650 Ω Coil Special Features: UL Coil Insulation Class B Industrial Panel Plug-In Monostable, DC 850 mW 650 Ω | Power Relay | Part Number: KHU-17D12-24 | Internal Number: 4-1393123-8 | TE Connectivity
Manufacturer Aliases
TE Connectivity / P&B has several brands around the world that distributors may use as alternate names. TE Connectivity / P&B may also be known as the following names:
- TE Connectivity Potter & Brumfield Relays
- TE CONNECTIVITY / POTTER & BRUMFIELD
- TE Connectivity / P&B Brand
- TYCO / P&B
- P&B
- Tyco Electronics / P&B
- P&B/TYCO
- P&B/Tyco Electronics
- TE CONNECTIVITY POTTER & BRUMFIELD (VA)
- Potter & Brumfield (Tyco - P&B)
- TYCO ELECTRONICS POTTER & BRUMFIELD (VA)
- TE CONNECTIVITY /POTT&BRUM
- TYCO ELECTRONICS / POTTER & BRUMFIELD
- TE CONNECTIVITY / P&B BRA
- P&B relay
- P&B - Potter & Brumfield
- TE Connectivity / P&
- T&B/TE CONNECTIVITY #155639
- TE CONN/P&B
- TYCO P/B ACCOUNT #354275-10-01
- TYCO ELECTRONICS / POTTER & BRUMFIELD
- POTTER& BRUMFIELD / TYCO
- TE Connectivity / P%26B Brand
- P&B/TE CONNECTIVITY
- TE Connectivity / P&B Asia
- Potter & Brumfield
Inventory History
3 month trend: Restocked
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
Contact MaterialCadmium, Silver
MountSocket
Number of Pins14
Number of Terminals14
Weight45 g
Technical
Coil Current38 mA
Coil Power850 mW
Coil Resistance650 Ω
Coil TypeNon-Latching
Coil Voltage (DC)18 V
Contact Current Rating5 A
Contact Resistance100 mΩ
Contact Voltage Rating (AC)240 V
Current Rating5 A
Insulation Resistance100 MΩ
Max Current Rating5 A
Max Operating Temperature70 °C
Max Voltage Rating (AC)120 V
Max Voltage Rating (DC)28 V
Min Operating Temperature-45 °C
Operate Time13 ms
PackagingBulk
Relay TypeGeneral Purpose
Release Time6 ms
Response Time13 ms
Schedule B8536410050
SealableDUST PROOF
TerminationPlug
Throw Configuration4PDT
Dimensions
Depth28.17 mm
Height38.1 mm
Length28.2 mm
Width21.8 mm
Datasheets & Documents
Download datasheets and manufacturer documentation for TE Connectivity / P&B KHU-17D12-24.
Compliance
Environmental Classification
China RoHSNon-Compliant
ELVNon-Compliant
RatingsCSA
REACH SVHCNo
RoHSCompliant
