HIROSE ELECTRIC DF1B-30DES-2.5RC
$ 0.593
Production
Inventory History
3 month trend: -5.76%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Datasheets & Documents
Download datasheets and manufacturer documentation for HIROSE ELECTRIC DF1B-30DES-2.5RC.
Related Parts
HIROSE ELECTRICDF1BA-30DEP-2.5RC
Connector Housing Wire to Board Plug 30 Position 2.5mm Straight Cable Mount Bag
HIROSE ELECTRICDF1BZ-22DP-2.5DSA
Pin Header, Wire-to-Board, 2.5 mm, 2 Rows, 22 Contacts, Through Hole Straight, DF1B
Descriptions
Descriptions of HIROSE ELECTRIC DF1B-30DES-2.5RC provided by its distributors.
Connector Housing Wire to Board Receptacle 30 Position 2.5mm Straight Cable Mount Bag
[Signalbee ] 2.5Mm Pitch Connectors For Discrete Wire (Ul/Csa Certified) |Hirose/hrs DF1B-30DES-2.5RC
Conn Housing PL 30 POS 2.5mm Crimp ST Cable Mount White Bag
Board Connector, 30 Contact(s), 2 Row(s), Female, 0.098 inch Pitch, Crimp Terminal, Locking, White Insulator, Socket
Headers & Wire Housings 2.5MM DOUBLE ROW 30P INLINE SOCKET
CONN RECEPT HOUSING 30POS 2.5MM
Manufacturer Aliases
HIROSE ELECTRIC has several brands around the world that distributors may use as alternate names. HIROSE ELECTRIC may also be known as the following names:
- HIROSE
- Hirose Electric Co Ltd
- HRS
- HIRO
- HIROSE ELECTRIC USA INC
- Hirose Connector
- HIROSE ELECT
- HRS(Hirose)
- HIROSE(HRS)
- HIROSE ELECTRIC UK LTD
- HIROS
- HIROSE ELECTRIC USA
- HIROSE ELECTRIC / HRS
- Hirose Electronic Co Ltd
- HIROSE ELECTRONIC
- Hirose Electric Americas
- HIROSE ELECTRIC GROUP
- Hirose Connectors
- HIROSE ELECTRIC EUROPE
- HIROSE ELECTRIC CO LTD (VA)
- Rose
- HIROSE ELECTRIC COMPANY LIMITE
- HIROSE (Strategic)
- 0533 HIROSE
- HIROSE(RoHS)
- Hirose Electric Co L
Inventory History
3 month trend: -5.76%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
ColorWhite
Dielectric MaterialPolyamide
Housing ColorWhite
Housing MaterialPolyamide
MountPanel, Snap-In
Number of Pins30
Technical
Connector TypeSocket
Contact GenderFemale
Contact Resistance30 mΩ
Current Rating3 A
Fastening TypeRamp
Insulation Resistance1 GΩ
Max Current Rating3 A
Max Operating Temperature85 °C
Max Voltage Rating (AC)250 V
Min Operating Temperature-35 °C
Number of Contacts30
Number of Positions30
Number of Rows2
Operating Force4.4 N
OrientationStraight
PackagingBulk
TerminationIDC
Dimensions
Contact Pitch2.5 mm
Depth11.5 mm
Height8.7 mm
Length46.4 mm
Pitch2.5 mm
Row Spacing2.4892 mm
Width11.5 mm
Wire Gauge (Max)20 AWG
Wire Gauge (Min)30 AWG
