Price and Stock
Authorized Distributors
Non-Authorized Stocking Distributors
Non-Authorized Dealers
| Distributor | SKU | Min | Pkg | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Farnell | 1217281 | 0 | 1 | 15h | ||||||||
| Microchip USA | OPB917B | 200 | 50 | Bulk | 3d | |||||||
| QUARKTWIN TECHNOLOGY LTD | OPB917B | Contact | 20h | |||||||||
| Nexxon Inc. (USA) | OPB917B | Contact | >1wk | |||||||||
| North Star Micro | NS-OPB917B | Contact | 6d |
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Descriptions
Descriptions of Optek OPB917B provided by its distributors.
Logic Output Slotted Switch, 1-Channel
SENSOR SWITCH LOGIC SLOTTED OPT
PHOTO SW. OPB917B
OPTO SWITCH, SLOTTED; Wavelength, Peak:880nm; Voltage, Vr Max:2V; Rise Time:50ns; Operating Temperature Range:-40°C to +80°C; External Depth:6.48mm; External Length / Height:25.65mm; Max Operating Temperature:80°C; Min Temperature Operating:-40°C; Width, External:30.73mm; Current, Supply:50mA; Fixing Centres:24.38mm; Fixing Hole Diameter:3.18mm; Input Current:7mA; Lead Length:24mm; Max Reverse Leakage Current:100µA; No. of Channels:1; No. of Pins:5; Optocoupler Type:Opto Switch; Output Type:Transistor; Power Dissipation:100mW; Voltage, Output:18V; Voltage, Output Max:35V; Width, Gap:5.08mm
Manufacturer Aliases
Optek has several brands around the world that distributors may use as alternate names. Optek may also be known as the following names:
- OPTEK TECHNOLOGY
- TT Electronics/Optek Technology
- OPTEK TECHNOLOGY INC
- OPT
- OPTE
- OPTEK TECH
- OPTEC
- OPTK
- Optek / TT Electronics
- Optek Technology/TT Electronics
- TT Electronics - Optek
- TT Optek
- OPTEK TEC
- OPTEK Technologies
- C- OPTEK
- OPTEK TECHNOLOG
- C-OPTEKTECH
- OPTEK MIL
- OPTEK TECH INC
- Kyocera Optrex
- BEDFORD OPTO TECHNOLOGY LTD
- OPTEK INC
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
MountChassis Mount, Through Hole
Number of Pins5
Technical
Fall Time50 ns
Forward Current50 mA
Forward Voltage1.3 V
Input Current20 mA
Max Operating Temperature80 °C
Max Power Dissipation100 mW
Max Reverse Leakage Current100 µA
Max Reverse Voltage (DC)2 V
Min Operating Temperature-40 °C
Min Supply Voltage4.5 V
Nominal Supply Current50 mA
Number of Channels1
Number of Circuits1
Number of Elements1
Operating Supply Current7 mA
Output Voltage35 V
Peak Wavelength880 nm
Power Dissipation100 mW
Response Time50 ns
Reverse Voltage (DC)2 V
Rise Time50 ns
Sensing Distance5.08 mm
Voltage Rating (DC)35 V
Dimensions
Height25.65 mm
Hole Diameter3.18 mm
Lead Length24 mm
Length30.73 mm
Width6.35 mm
