STMicroelectronics L7905CP
$ 0.591
Production
Inventory History
3 month trend: -5.30%
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Datasheets & Documents
Download datasheets and manufacturer documentation for STMicroelectronics L7905CP.
CAD Models
Download STMicroelectronics L7905CP symbol, footprint, and 3D STEP models from our trusted partners.
| SOURCE | eCAD | mCAD | FILES |
|---|---|---|---|
 Component Search Engine | SymbolFootprint | 3D | Download |
 EE Concierge | SymbolFootprint | ||
 SnapEDA | SymbolFootprint | 3D | Download |
The partner site will open in a new tab when downloading their CAD models
By downloading CAD models from Octopart, you agree to our Terms & Conditions and Privacy Policy.
Descriptions
Descriptions of STMicroelectronics L7905CP provided by its distributors.
Standard Regulator Neg -5V 1.5A 3-Pin(3+Tab) TO-220FP Tube
L7905 Series 1.5 A -5 V Fixed Output Negative Voltage Regulator -TO-220FP
Linear Fixed Voltage Regulator -5V 1.5A TO-220FP
STMICROELECTRONICS L7905CPFixed LDO Voltage Regulator, -35V to -10V, 1.4V Dropout, -5Vout, 1.5Aout, TO-220FP-3
L7905CP, SINGLE NEGATIVE VOLTAGE REGULATOR 1.5A -5 V, 3-PIN TO-220FP
IC REG LINEAR -5V 1.5A TO220FP
NEGATIVE VOLTAGE REGULATOR Fixed Negative Standard Regulator, 5V, BIPolar
IC, V REG -5.0V, 7905, TO-220FP-3; Output Type: Fixed; Input Voltage Min: -35V; Input Voltage Max: -10V; Fixed Output Voltage Nom.: -5V; Adjustable Output Voltage Min: -; Adjustable Output Voltage Max: -; Output Current: 1.5A;
Ldo, Fixed, -5V, 1.5A, 0 To 150Deg C; Output Type:Fixed; Input Voltage Min:-35V; Input Voltage Max:-10V; No. Of Outputs:1Outputs; Output Voltage - Nom:-5V; Output Voltage Min:-; Output Voltage Max:-; Polarity:Negative Output; Msl:- Rohs Compliant: Yes |Stmicroelectronics L7905CP
