Avago ASSR-V622-002E
$ 2.856
Production
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
CAD Models
Download Avago ASSR-V622-002E symbol, footprint, and 3D STEP models from our trusted partners.
| SOURCE | eCAD | mCAD | FILES |
|---|---|---|---|
 Component Search Engine | SymbolFootprint | 3D | Download |
The partner site will open in a new tab when downloading their CAD models
By downloading CAD models from Octopart, you agree to our Terms & Conditions and Privacy Policy.
Descriptions
Descriptions of Avago ASSR-V622-002E provided by its distributors.
Optocoupler Drive 2-CH 8-Pin PDIP Tube
Dual Channel Photovoltaic MOSFET Driver (6.5V/15µA)
OPTOCOUPLER PHOTVO 3.75KVRMS DIP
OPTOISO 3.75KV 2CH PHVOLT 8DIP
RELAY, SSR, 15UA, 6.5V, DIP8; Series:ASSR-V62X; Current, Surge:300mA; Terminal Type:THT; Current Rating:15µA; No. of Pins:8; Relay Case Style:DIP; Voltage, Load DC Max:6.5V
Manufacturer Aliases
Avago has several brands around the world that distributors may use as alternate names. Avago may also be known as the following names:
- AVAGO TECHNOLOGIES
- AVA
- AVAGO TECH
- AVANTEK
- AVG
- AVASEM
- Avago Technologies US Inc
- HEWLETT
- AVAG
- AGA
- AVAGO TECHNOLOGIES INC
- DDI
- AVAGO(Broadcom)
- AVGO
- AGILENT TECHNOLOGIES INC
- Avago Technology
- AVAGO TECHNOLOG
- AVAGO TECHNO
- Avantek Inc
- Avago Technologies (Broadcom Limited)
- Broadcom Avago
- AGLIENT
- AVANTEK SYSTEMS
- Avago Technologies/Broadcom
- AVAGO TECHNOLOGIES US INC (VA)
- Avago Technologies US Inc.
- Broadcom
Inventory History
Inventory history trend unavailable
CAD Models
Download symbol, footprint, and 3D STEP
Alternate Parts
0 parts available
Technical Specifications
Physical
Case/PackagePDIP
Contact PlatingTin
MountThrough Hole
Number of Pins8
Technical
Forward Current30 mA
Forward Voltage1.3 V
Input Current30 mA
Isolation Voltage3.75 kV
Load Current15 mA
Max Input Current30 mA
Max Operating Temperature85 °C
Max Output Voltage7 V
Max Power Dissipation100 mW
Min Operating Temperature-40 °C
Number of Channels2
Number of Circuits2
Number of Elements2
Output Current per Channel20 µA
Power Dissipation100 mW
Reverse Breakdown Voltage5 V
TerminationGull Wing
Throw ConfigurationDPST
Compliance
Environmental Classification
China RoHSCompliant
Lead FreeLead Free
Radiation HardeningNo
REACH SVHCYes
RoHSCompliant
