가격 및 재고
| Distributor | SKU | Min | Pkg | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DigiKey | 706-1310-1-ND | 5,969 | 1 | Cut Tape | ||||||||
| Arrow Electronics | IS62C256AL-45ULI-TR | 1,720 | 80 | |||||||||
| Verical | IS62C256AL-45ULI-TR | 1,720 | 80 | |||||||||
| Avnet | IS62C256AL-45ULI-TR | 0 | 1K | 10h | ||||||||
| Mouser | 870IS62C256AL45ULITR | 2,918 | 1 | Tape & Reel |
대체 부품
Price @ 1000
$ 1.244
$ 1.443
Stock
291,235
275,007
Authorized Distributors
5
6
Case/Package
SOP
SOP
Number of Pins
28
28
Memory Type
RAM, SRAM - Asynchronous
RAM, SRAM - Asynchronous
Density
256 kb
256 kb
Address Bus Width
15 b
15 b
Access Time
45 ns
45 ns
Frequency
-
-
Interface
Parallel
Parallel
Min Supply Voltage
4.5 V
4.5 V
Max Supply Voltage
5.5 V
5.5 V
공급망
Country of OriginMainland China, Taiwan
Export Control Classification Number (ECCN) CodeEAR99
Harmonized Tariff Schedule (HTS) Code8542.32.00.41
Introduction Date2005-06-02
Lifecycle StatusProduction (Last Updated: 1 year ago)
관련 부품
Alliance MemoryAS6C62256-55SIN
AS6C62256 Series 256-kbit (32 K x 8) 3.3 V 55 ns CMOS Static RAM - SOIC-28
LPC11xx Series 4 kB Flash 1 kB RAM 50 MHz 32-Bit Microcontroller - SOIC-20
EAR99 Surface Mount Tape & Reel (TR) SRAM - Asynchronous ic memory 35ns 20.445mm 30mA 1Mb
Alliance MemoryAS6C6264-55SCN
AS6C6264 Series 64-kbit (8 K x 8) 3 V 55 ns CMOS Static RAM - SOIC-28
설명
유통업체에서 제공한 ISSI IS62C256AL-45ULI-TR에 대한 설명입니다.
EAR99 Surface Mount Tape & Reel (TR) 32KX8 ic memory 45ns 2.84mm 25mA 256kb
SRAM Chip Async Single 5V 256K-bit 32K x 8 45ns 28-Pin SOP T/R
32K X 8 LOW POWER CMOS STATIC RAM
256K, low Power, async,32K X 8,45Ns,5V,28 Pin Sop, Rohs |Integrated Silicon Solution (Issi) IS62C256AL-45ULI-TR
Standard SRAM, 32KX8, 45ns, CMOS, PDSO28
Serial SRAM, 32Kx8, 5V, SOP-28, RoHS
ISSI SCT
Static Random Access Memory (SRAM)
IC SRAM 256KBIT PARALLEL 28SOP
제조업체 별칭
ISSI에는 유통업체가 대체하여 사용할 수 있는 전 세계 여러 브랜드가 있습니다. ISSI는 다음 이름으로도 알려져 있습니다:
- ISSI Integrated Silicon Solution Inc
- ICSI
- ISS
- Integrated Silicon Solution Inc
- INTEGRATED SILICON SOLUTION
- Integrated Silicon Solution Inc (ISSI)
- Integrated Silicon Solutions
- INTEGRATED SILICON S
- INTEGRATED SILICON SOLUTION (ISSI)
- INTEGRATED CIRCUIT SOLUTION
- ISSI(Integrated Silicon Solution)
- INTEGRATED SILICON SOLUTIONS (ISSI)
- ISSI INC
- Integrated Circuit Solution Inc
- ISSI/ICSI
- INTEGRATED SILICON SOLUTIONS INC
- INTEGRATED SILICON SOLUTI
- INTEGRATED CIRCUIT SOLUTI
- ISSI/INTEGRATED
- ISSI Integrated Silicon Solut
- ISSI (INTEGRATED SILICON SOLUTIONS)
- ISSI Integrated Silicon
- ISSI (INTEGRATED SILICON SOLU
- Integrated Silicon Solutions Inc(ISSI)
- ISSI/HIT
기술 사양
Physical
Case/PackageSOP
Number of Pins28
Number of Terminals28
Technical
Access Time45 ns
Address Bus Width15 b
Density256 kb
InterfaceParallel
Max Operating Temperature85 °C
Max Supply Voltage5.5 V
Memory TypeRAM, SRAM - Asynchronous
Min Operating Temperature-40 °C
Min Supply Voltage4.5 V
Nominal Supply Current25 mA
Number of Circuits1
Number of Ports1
Number of Words32000
Operating Supply Voltage5 V
PackagingTape & Reel
Schedule B8542320040
Sync/AsyncAsynchronous
Temperature GradeIndustrial
Word Size8 b
Dimensions
Height - Seated (Max)2.84 mm
Length18.11 mm
Terminal Pitch1.27 mm
Width8.405 mm
