United Chemi-Con EKMH101VNN472MA50T
관련 부품
United Chemi-ConEKMH101VSN472MA50S
Cap Aluminum Lytic 4700uF 100V 20% (35 X 50mm) Snap-In 10mm 0.053 Ohm 3800mA 2000h 105C
United Chemi-ConEKMH101VRD472MA50T
Cap Aluminum Lytic 4700uF 100V 20% (35 X 50mm) Solder Pin 0.053 Ohm 3800mA 2000h 105°C
United Chemi-ConEKMH800VSN472MR50T
Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 80V, 20% +Tol, 20% -Tol, 4700uF
PanasonicECOS2AA472EA
Cap Aluminum 4700uF 100V 20% (35 X 50mm) 10mm 0.053 Ohm 3800mA 3000 hr 105°C Bulk
Rubycon100MXG4700MEFCSN35X40
Radial Can - Snap-In ALUMINUM ELECTROLYTIC CAPACITOR MXG 100V 4700muF ±20% 1.378Dia 35.00mm
PanasonicECE-T2AA472EA
Cap Aluminum 4700uF 100V 20% (35 X 50mm) Snap-In 0.053 Ohm 3800mA 3000h 105°C Bulk
설명
유통업체에서 제공한 United Chemi-Con EKMH101VNN472MA50T에 대한 설명입니다.
Cap Aluminum Lytic 4700uF 100V 20% (35 X 50mm) Snap-In 10mm 0.053 Ohm 3800mA 2000h 105°C
ALUMINUM ELECTROLYTIC CAPACITOR
CAP ALUM 4700UF 20% 100V SNAP
제조업체 별칭
United Chemi-Con에는 유통업체가 대체하여 사용할 수 있는 전 세계 여러 브랜드가 있습니다. United Chemi-Con는 다음 이름으로도 알려져 있습니다:
- UCC
- CHEMI-CON
- UNITED CHEMI-CON INC
- UNITED CHEMI
- NIPPONCHEM
- UNITED CHEM
- CHEMI
- MARCON
- MARC
- United Chemi-Con (UCC)
- EUROPE CHEMI-CON
- UNITED CHE
- UNITED CH
- UNITED CHEMI-CON (VA)
- CHEMIC
- United Chemi-Con/Nippon Chemi-Con
- UNITED CEHMI
- NIPPON (UNITED) CHEMI-C
- Nippon / United Chemi-Con (UCC)
- UNITED CHEMI-C
- SINGAPORE CHEMI-CON (PTE) LTD
- NIPPON
- NIPPON-UCC
- CHEMI-COM
- Taiwan Chemi-Con
기술 사양
Physical
Case/PackageRadial
MountThrough Hole
Technical
Capacitance4.7 mF
ESR (Equivalent Series Resistance)53 mΩ
Life (Hours)2000 hours
Max Operating Temperature105 °C
Min Operating Temperature-40 °C
PackagingBulk
Ripple Current3.8 A
TerminationSnap in
Tolerance20 %
Voltage Rating100 V
Voltage Rating (DC)100 V
Dimensions
Diameter35 mm
Height - Seated (Max)51.9938 mm
Lead Diameter1 mm
Lead Pitch10.0076 mm
Length50 mm
