설명
유통업체에서 제공한 Phoenix Contact 2966595에 대한 설명입니다.
Phoenix 2966595 Miniature Solid-State Relay 24V DC Input 3-33V DC/3A Output
Relay SSR 7mA 1.2V DC-IN 33V DC-OUT 4-Pin
Phoenix Contact Interface Miniature Solid-State Relay; OPT-24DC/24DC/2; 3A; 1NO; 24VDC IN; 24VDC OUT
Phoenix Contact Miniatuur-solid-state-relais OPT-24DC/ 24DC/ 2 - 2966595
SOLID STATE RELAY, SPST-NO, 3A, 28.8V ROHS COMPLIANT: YES
제조업체 별칭
Phoenix Contact에는 유통업체가 대체하여 사용할 수 있는 전 세계 여러 브랜드가 있습니다. Phoenix Contact는 다음 이름으로도 알려져 있습니다:
- PHOENIX
- PHEONIX
- PHO
- PHOENI
- PHX
- PHOE
- PHOENIX CONTACT INC
- PHOENIX CONTACTS
- PHOENX
- PHOENIX CONT
- PHOENIX CONTACT GMBH & CO KG
- PHOENIX CONTAC
- PHEONIX CONTACT
- Phoenix Contact GmbH & Co KG
- PHOENIX CONTACT POWER
- Phoenix Contact Canada
- Phoenix Contact GmbH & Company
- PHOENIX CONTACT INC - POWER
- Picker Components
- PHOENIX CONTACT (VA)
- Phoenix Contact Deutschland GmbH
- PHOENIXUS
- PHOENIX CONTACT GMBH and COKG
- PHÖNIX CONTACT
- Phoenic Contact
- Phoenix Contact AG
기술 사양
Physical
Case/PackageSIP
MountSocketable, Through Hole
Number of Pins4
Weight5.219998 g
Technical
Coil Voltage (AC)24 V
Current Rating3 A
Data PolarityDC
Forward Current7 mA
Input Current7 mA
Load Current3 A
Max Operating Temperature60 °C
Min Operating Temperature-25 °C
Number of Elements1
Operating Supply Voltage24 V
Power Consumption140 W
Relay TypeRelay
Schedule B8536410030
TerminationPlug
Throw ConfigurationSPST
Voltage Rating (DC)33 V
Dimensions
Height15 mm
Max Length28 mm
Width5 mm
