説明
NKK Switches S21AWFの詳細は販売業者から提供されます。
Switch Toggle ON None OFF DPST Round Lever Solder Lug 15A 250VAC 30VDC Panel Mount with Threads
Toggle Switch, DPST, On-off, 20A, 30VDC, Quick Connect Terminal, Toggle Actuator, Panel Mount
SWITCH, TOGGLE, SEALED, DPST, ON-NONE-OFF, NON-ILLUM,17.50MM ACT,15A,125VAC,.250" QC
SWITCH, TOGGLE, DPST, 15A, 250VAC
SWITCH, TOGGLE, DPST, 15A, 250VAC; Contact Configuration:DPST; Switch Operation:On-None-Off; Voltage AC Nom:250V; DC Nom:30V;
Switch, Toggle, Dpst, 15A, 250Vac; Switch Operation:On-Off; Contact Configuration:Dpst; Illumination:Non Illuminated; Product Range:S Series; Switch Mounting:Panel Mount; Contact Current Max:15A; Contact Voltage Ac Nom:250V Rohs Compliant: Yes |Nkk Switches S21AWF
メーカーの別名
NKK Switchesは世界中でいくつかのブランドを持っており、販売業者が代替名として使用するかもしれません。 NKK Switches は以下の名前でも知られているかもしれません：
- NKK
- NIHON
- NIKKAI
- NKK SWITCH
- NKK Switches of America Inc
- NKK SWITCHES CO LTD
- Nihon Kaiheiki Ind
- NIHON-KAIHEIKI
- NKK SWITCHES OF AMERICA
- NKK Switches (Nihon Kaiheiki Ind)
- Nihon Kaiheiki Kougyou
- NKK SWITC
- NKK SWITCHES (VA)
- NIKKAI (NKK)
- NKK CORPORATION
- NKK SWITCHES IF AMERICA
- NKK MICRO DEVICES INC
- NKKMICRODEVICES
- NKK SWITCHES INC
- NKK/NONE
- NKK CORP
技術仕様
Physical
Actuator MaterialBrass
Contact PlatingSilver
Dielectric MaterialPhenolic
MountPanel
Terminal MaterialBrass
Technical
Contact Current Rating15 A
Contact Resistance10 mΩ
Contact Voltage Rating (AC)250 V
Current Rating20 A
Electrical Life25 kcycles
Illumination TypeIlluminated, Non-Illuminated
Insulation Resistance1 GΩ
Max Current Rating20 A
Max Operating Temperature70 °C
Max Voltage Rating (DC)30 V
Min Operating Temperature-10 °C
Switch FunctionOn-Off
TerminationQuick Connect
Throw ConfigurationDPST
Voltage Rating (AC)125 V
Voltage Rating (DC)30 V
Dimensions
Actuator Length17.5006 mm
Height20.0152 mm
Length31.1912 mm
