説明
Sensata MCPC2490Aの詳細は販売業者から提供されます。
Relay SSR 30mA 32V DC-IN 90A 280V AC-OUT 6-Pin
Proportional Control SSR, Panel Mount, 280VAC/90A, 0-5VDC Control
Solid State Relays - Industrial Mount PM Prop.-Controller 0-5V In
SSR RELAY SPST-NO 90A 180-280V
Trigger Output SSR, 1-Channel, 4000V Isolation
Ssr, Panel Mount, Spst-No, 32Vdc, 90A
CST Crydom Microcontroller SSR, Pha
MICROCONTROLLER SSR, PHASE CONTROL
メーカーの別名
Sensataは世界中でいくつかのブランドを持っており、販売業者が代替名として使用するかもしれません。 Sensata は以下の名前でも知られているかもしれません：
- Sensata Technologies
- Sensata-Crydom
- Sensata-Cynergy3
- Sensata Technologies Inc
- SENSATA TECH
- SENSATA / GIGAVAC
- Sensata Technologies – Crydom
- Sensata | Gigavac Industrial
- Sensata-Kavlico
- Sensata Technologies – Airpax
- SENSATA / GIGAVAC CLEAN ENERGY
- Sensata Pressure & Temp
- Sensata-DeltaTech
- Sensata / Magnum Dimensions
- SENSATA TECHNOLOGIE
- SENSATA TECHNOLOGIES HOLLAND BV
- SENSATA / BEI KIM
- Airpax / Sensata
- SENSATA POWER CONTROLS
- SENSATA TECHNOLOGIES (KLIXON)
- SENSATA PRESSURE
- SENSATA TECHNOLOGI
- Sensata-Airpax
- FIRST TECHNOLOGY
- SENSATA TECHNOLOGIES MARYLAND
技術仕様
Physical
MountChassis Mount, Panel, Screw
Number of Pins6
Technical
Data PolarityDC
Forward Current1.25 mA
Input Current28 A
Isolation Voltage4 kV
Load Current90 A
Max Input Current30 mA
Max Operating Temperature80 °C
Min Operating Temperature-20 °C
Number of Elements1
Operating Supply Voltage280 V
Relay TypeRelay
TerminationScrew
Throw ConfigurationSPST
Dimensions
Height22.9 mm
Length58.4 mm
Max Length58.4 mm
Width45.7 mm
