Eaton FWH-600A
$ 434.465
Production
Precio y existencias
Distribuidores autorizados
Distribuidores no autorizados
Vendedores no autorizados
Historial de existencias
Tendencia de 3 meses: -100%
Modelos CAD
Descargar símbolo, footprint y 3D STEP
Componentes alternativos
0 piezas disponibles
Cadena de suministros
Export Control Classification Number (ECCN) CodeEAR99
Introduction Date2001-10-16
Lifecycle StatusProduction (Last Updated: 5 months ago)
Descripciones
Descripciones de Eaton FWH-600A suministradas por sus distribuidores.
Fuse, Industrial / Power, 600 A, 500 VAC, 500 VDC, 50.8mm x 110.24mm, 2" x 4.34"", High Speed"
Electric Fuse, Fast Blow, 600A, 500VAC, 500VDC, 200000A (IR), Inline/holder
SEMICONDUCTOR FUSE; Voltage Rating VDC:500V; Voltage Rating VAC:500V; Fuse Current:600A; Fuse Size Imperial:2" x 2.09"; Series:FWH; Blow Characteristic:Fast Acting ;RoHS Compliant: Yes
COOPER BUSSMANN FWH-600A Fuse, 600A, FWH, 500VAC/DC. More details: Fuse, 600 Fuse Amps, Nonindicating, FWH Series, 500VAC/DC Voltage Rating, Fast Acting, Single Element, Fiberglass Body Material, Nonrejection, Body Style Bolt On, Interrupt Rating 200kA at 500VAC, 50kA at 500VDC, Length 4-11/32 In., Diameter 2 In., Functionally Equal To Ferraz/Gould A50P, Littelfuse L50S, Standards CE, UL Recognized, CSA Certified
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
Alias de fabricantes
Eaton tiene diversas marcas a nivel mundial que los distribuidores pueden usar como nombres alternativos. Eaton también podría ser conocido por los siguientes nombres:
- Eaton - Electronics Division
- EATON CORPORATION
- Eaton - Bussmann Electrical Division
- EATON CORP
- Eaton Electronics
- EAT
- EATON/COMMERCIAL CONTROLS
- EATON AEROSPACE
- Eaton Bussmann
- Eaton Electrical
- EATON/AEROSPACE CONTROLS
- EATON EMOBILITY TRANSPORTATION
- EATON POWERWARE/MGE OFFICE PROTECTION
- EATON ELECTRIC
- EATON AERO
- EATON BUSSMANN ELECTRICAL
- EATON AEROSPAC
- Eaton Switches
- EATON ELE
- EATON/C&H
- Eaton Moeller
- EATON SWITZERLAND
- Eaton Interconnect
- Eaton / Circuit Breakers
- EATON CHAR-LYNN
Historial de existencias
Tendencia de 3 meses: -100%
Modelos CAD
Descargar símbolo, footprint y 3D STEP
Componentes alternativos
0 piezas disponibles
Especificaciones técnicas
Physical
MountBolt
Number of Pins2
Weight453.59237 g
Technical
Current600 A
Current Rating600 A
Max Power Dissipation108 W
Max Voltage Rating (AC)500 V
PackagingBox
Power Dissipation108 W
TypeElectrical
Voltage Rating (AC)500 V
Voltage Rating (DC)500 V
Dimensions
Diameter50.8 mm
Height53.09 mm
Length50.8 mm
