Mean Well ELP-75-24
$ 25.9
Production
Precio y existencias
Distribuidores autorizados
Distribuidores no autorizados
Vendedores no autorizados
Historial de existencias
Tendencia de 3 meses: +0.00%
Modelos CAD
Descargar símbolo, footprint y 3D STEP
Componentes alternativos
0 piezas disponibles
Fichas técnicas y documentos
Descargar fichas técnicas y documentación del fabricante para Mean Well ELP-75-24.
Componentes relacionados
Mean WellHLP-60H-24
POWER SUPPLY, AC-DC,24V,2.5A,100-305V IN, OPEN FRAME, PFC, LED DRIVER, HLP-60H SERIES
Mean WellHLN-60H-24B
Enclosed Switching LED Driver Power Supply 24 Volts 2.5 Amps 60 Watts 3 in 1 Dimming Function
Descripciones
Descripciones de Mean Well ELP-75-24 suministradas por sus distribuidores.
AC-DC Power Factor Correction Module, 1 Output, 75.6W, Hybrid
AC/DC Power Supply Single-OUT 24V 3.15A 75.6W 9-Pin
O/P +24V3.15A; General PCB; AC/DC; Open PCB; Open Frame
ELP-75-24 MEAN WELL AC-DC 24 Volt 3.15 Amp 76 Watt Power Supply +More!
Switching Power Supplies 75.6W 24V 3.15A W/PF C Function Open Frame
75.6W, 1 OUTPUT, EMBEDDED SWITCH MODE POWER SUPPLY (SMPS), 24V DC, 3.15A
AC/DC 75W 24V Single Output Power Supply, Open Frame
Power Supply Switching PFC Open Frame 75.6 Watt 24VDC@3.15A
AC/DC Open Frame Power Supply, Industrial & ITE, Adjustable, Fixed, 1 Output, 75.6 W, 24 V, 3.15 A
24Vdc 3.15A 24Vdc Open Frame Power Supply No Load Power
Outputs = 1 / Output Voltage 1 V = 24 / Output Voltage Nominal 1 V = 24 / Output Current 1 A = 3.15 / Output Type = Adjustable / Rated Power W = 75.6 / Input Voltage Min. V = 90 / Input Voltage Nominal = 100 ... 240 VAC / Input Voltage Nominal = 120 ... 370 VDC / Input Voltage Max. V = 264 / Efficiency % = 90 / MTBF h = 345300 / Termination Type = Pin Connector / Ripple & Noise (V) mV = 240 / Operating Temperature Min. °C = -30 / Operating Temperature Max. °C = 70 / Length mm = 175 / Width mm = 60 / Height mm = 27 / Warranty = 3 Years
Alias de fabricantes
Mean Well tiene diversas marcas a nivel mundial que los distribuidores pueden usar como nombres alternativos. Mean Well también podría ser conocido por los siguientes nombres:
- MEAN WELL USA Inc
- Mean Well Enterprises
- MEAN WELL Enterprises Co Ltd
- MEAN WELL USA
- MEA
- MW(MEAN WELL Enterprises)
- MEANW
- FRANMARK
- MEAN WELL POWER SUPPLIES
- Mean Well Electronic Co Ltd
- MW (MEAN WELL)
- M+R MULTITRONIK GMBH
- MEAN WELL EUROPE BV
Historial de existencias
Tendencia de 3 meses: +0.00%
Modelos CAD
Descargar símbolo, footprint y 3D STEP
Componentes alternativos
0 piezas disponibles
Especificaciones técnicas
Physical
MountScrew
Number of Pins9
Weight250 g
Technical
Efficiency90 %
Max Input Current1.8 A
Max Input Voltage264 V
Max Operating Temperature70 °C
Max Output Current3.15 A
Max Output Power75.6 W
Max Output Voltage26.4 V
Min Input Voltage90 V
Min Operating Temperature-30 °C
Min Output Voltage21.6 V
Nominal Input Voltage115 V
Nominal Output Voltage24 V
Number of Circuits1
Number of Outputs1
Output Current3.15 A
Output Power75.6 W
Output Voltage24 V
Power Rating75.6 W
Dimensions
Depth60 mm
Height27.94 mm
Height - Seated (Max)31 mm
Length175 mm
Width60 mm
